THE CIRCULAR SAW-LUTION
The INFINI Brand Circular Saw cutting machines will ensure the peace of mind to its users owing to many high-end and first of its kind characteristics like:
- Graded Cast Iron Structure
- Rigid Gear Box
- Motion Control System
- Inverter Duty Motor
- Absolute Servo Motor Technology
- Rigid Material Feeding Mechanism
- Lowest Remanent Piece Length
- Inclined Cutting Axis
- Saw Blade Support & Cleaning
- Ergonomic Design
- Motorized Blade Cleaning Brush
- Ease of operation and Maintenance
- Vertical Electrical Panel with Highest of Safety Standards
- Efficient Chip management
- Low Skill Operability
- Standard Make if Brought-out items
TECHNICAL SPECIFICATIONS:
| Model | TA-80 | TA-110 |
| Capacity – Round Bar | 10-80 mm | 20-110 mm |
| Capacity – Square Bar | 10-65 mm | 20-80 mm |
| Saw Blade Size | 285 x 32 x 2.0 mm | 360 x 40 x 2.6 mm |
| Saw Blade Speed Range | 50-160 RPM | 50-150 RPM |
| Material Length – Single Feed | 6 – 700 mm | 8 – 700 mm |
| Material Length – Multi Feed | 6 – 6000 mm | 8 – 6000 mm |
| Remnant Length | 65 mm + Cut Length | 70 mm + Cut Length |
| Cutter Motor Power | 9.3 KW | 11 KW |
| Hydraulic Tank Capacity | 80 Ltr | 80 Ltr |
| Gross Weight (With Loader) | 3500 Kg | 3800 Kg |
| Control System Type | Motion Control | Motion Control |
| Power Supply | 3 Phase 415 V AC | 3 Phase 415 V AC |
